  • 1756-OF8I Allen-Bradley ControlLogix 1756 Isolated Analog I/O Modules
1756-OF8I Allen-Bradley ControlLogix 1756 Isolated Analog I/O Modules

1756-OF8I Allen-Bradley ControlLogix 1756 Isolated Analog I/O Modules


  • Estimated Lead Time : Usually ships in 1-10 working days.
  • Manufacturer : Allen-Bradley
  • Product No. : 1756-OF8I
  • Product type : ControlLogix 1756 Isolated Analog I/O Modules
  • 1756-OF8I General Purpose Current Voltage Analog Output Module
  • Provides faster performance, accuracy and per channel configuration for either current or voltage
  • Inputs/ Outputs :  8 isolated channels - Any combination of Voltage or Current mode
  • Input/Output Ranges :
  • ±10V
  • 0...10V
  • 0...5V
  • 0...20 mA
  • Current draw @ 5.1V : 200 mA
  • Thermocouple Types : N/A
  • Current draw @ 24V : Voltage or Current mode with 250 O loads = 220 mA
  • Total backplane power : Voltage mode = 6.3 W
  • Power dissipation, max : Voltage mode = 5.4 W
  • Thermal dissipation : Voltage mode = 18.4 BTU/hr
  • Output impedance : 46 (Current output)
  • Overvoltage protection : ±30V DC (voltage/current)
  • Drive capability: Current output = 0…1000 O
  • Calibrated accuracy @ 25 °C (77 °F) :  0.05%
  • Module error over full temperature range : 0.1%
  • Module conversion method :  R-Ladder DAC, monotonicity with no missing codes
  • Module keying : Electronic, software configurable
  • Slot width : 1
  • Shipping weight : 3 kg
  •
